Plan 2328
- Regular price
- $495.00
- Regular price
-
$2,000.00 - Sale price
- $495.00
- Unit price
- per
Couldn't load pickup availability
Item Overview
• Instant Digital Download: 1 PDF included
• Handmade item
Item Details:
This home has a total area of 2,949 square feet and is designed to accommodate a large family or provide plenty of room for guests. The house features five bedrooms, including a spacious master suite, and three full bathrooms.
The main living area could be located on the first floor, with an open-plan layout that includes a large living room, dining area, and kitchen. The living room could have a fireplace, large windows, and plenty of space for relaxing or entertaining. The dining area could be adjacent to the kitchen, which could feature an island, modern appliances, and plenty of counter space and storage.
Also on the first floor could be a home office or study, a laundry room, and perhaps a guest bedroom with access to a full bathroom.
The second floor could feature the remaining bedrooms, including the master suite. The master bedroom could be spacious and luxurious, with a large walk-in closet and a master bathroom that includes a soaking tub, separate shower, and double sinks. The other four bedrooms could share two full bathrooms, providing plenty of privacy and convenience for everyone in the household.
The house is designed with a two-car garage, which could be located at the front of the house or on the side, depending on the lot's configuration.
The architectural style of the house could vary, but it is likely to be a modern or contemporary design with clean lines and a focus on functionality. The house is perfect for a large family who needs plenty of space for everyone to spread out and have their own private areas while still having comfortable and inviting shared spaces for spending time together.
What's Included in Your Plan
When you purchase this plan, you’ll receive a comprehensive set of digital drawings and details to guide you through every step of building your dream home. Each plan includes the following:
Drawings Included:
- Presentation Drawing: A visual overview of the design, showcasing the aesthetic and layout.
- Working Drawing: Detailed drawings that include all necessary construction notes and specifications.
- West & East Elevation: Side views of the house, showing the heights and finishes from the west and east perspectives.
- South & North Elevation: Front and rear views of the house, outlining the heights and finishes from the south and north perspectives.
- Section A-A': A cross-sectional view that details the interior structure along the A-A’ line.
- Section B-B': A cross-sectional view that details the interior structure along the B-B’ line.
- Section C-C': A cross-sectional view that details the interior structure along the C-C’ line.
- Structural Layout: The foundational framework, including floor layouts and roof structures.
- Wall Framing Details: Specifics on how each wall is constructed, including dimensions and materials.
- Post Details: Information on the structural posts that support the building.
- Header Details: Detailed drawings of the header construction above windows and doors.
- Steel Truss Details: Layout and specifications for any steel trusses used in the structure.
- Joining Details: Information on how various elements of the building are connected.
- Electrical Drawing: A layout of the electrical plan, including the placement of outlets, switches, and fixtures.
- Plumbing Drawing: Detailed plumbing layout, showing the placement of pipes, fixtures, and connections.
- Material List: A comprehensive list of materials required for the construction of your home.
- Slab Details: Information regarding the foundation slab, including dimensions and materials used.
Source Files Included:
- CAD Files: Editable CAD files to modify and adapt the design to your specific needs.
- SketchUp Files: 3D SketchUp models for a detailed and interactive view of the design.
Important Notes:
- Digital Files Only: No physical printed plans are included with your purchase. All files are provided in a digital format for your convenience.
- Consult a Professional: It is highly recommended to consult with a licensed builder or architect to ensure compliance with local building codes and regulations.
- Personal Use Only: These plans are intended for personal use only. Redistribution, resale, or sharing of the files is strictly prohibited.
- No Returns: Due to copyright laws and the nature of digital products, returns or exchanges are not available.
This plan is perfect for anyone looking to build their dream home with a touch of elegance and modern house aesthetic. Ready to bring your vision to life? Download your plan today and take the first step towards your serene homestead retreat.
