Plan 2404 | Barndominium

No review yet. Write Review
Regular price
$995.00
Regular price
$2,000.00
Sale price
$995.00

Vendor : Dream Home Plans

Product Type :

Hurry! Only
0
units left in stock!
Trusted Image

This stunning Barndominium home offers a perfect blend of bold design and functionality. The exterior showcases strong colours, wood accents, and stonework, with 88 feet in length, 57 feet in width with 12-feet wide front porch ideal for gatherings. The side-entry garage features oversized bays—one double, one single—providing approximately 1,500 square feet of unheated space for vehicles, storage, or a workshop.

Inside, the home spans 3,100 square feet of heated living space across two floors, including four bedrooms and three-and-a-half baths. Triple French doors open into the voluminous family room with a fireplace, adjacent to the dining room, both featuring high ceilings. The kitchen has an island and a nearby pantry, with convenient access to the mudroom, laundry room, and powder room.

The main floor’s primary suite offers a large walk-in closet and a luxurious ensuite bath with a freestanding tub, separate shower, and double vanities. Upstairs, three additional bedrooms include walk-in closets, with one bedroom enjoying a private bath. The other two share a Jack and Jill bath. A large, vaulted loft overlooks the dining room, completing this well-designed family home.


Details
Total Heated Area: 3,100 sq. ft.
First Floor: 1,973 sq. ft.
Second Floor: 1,127 sq. ft.

UNHEATED Sq Ft
Garage: 1,519 sq. ft.

Floors: 2
Bedrooms: 4
Bathrooms: 3
Half Baths: 1
Garages: 3 cars

BUILDING DETAILS
Width: 88ft.
Depth: 53 ft.
Height: 29ft.-6in.
Main Roof Pitch: 6:12
Exterior Framing: 2x4

CEILING HEIGHTS
First Floor: 9 feet
Second Floor: 9 feet

What's Included in Your Plan

When you purchase this plan, you’ll receive a comprehensive set of digital drawings and details to guide you through every step of building your dream home. Each plan includes the following:

Drawings Included:

  • Presentation Drawing: A visual overview of the design, showcasing the aesthetic and layout.
  • Working Drawing: Detailed drawings that include all necessary construction notes and specifications.
  • West & East Elevation: Side views of the house, showing the heights and finishes from the west and east perspectives.
  • South & North Elevation: Front and rear views of the house, outlining the heights and finishes from the south and north perspectives.
  • Section A-A': A cross-sectional view that details the interior structure along the A-A’ line.
  • Section B-B': A cross-sectional view that details the interior structure along the B-B’ line.
  • Section C-C': A cross-sectional view that details the interior structure along the C-C’ line.
  • Structural Layout: The foundational framework, including floor layouts and roof structures.
  • Wall Framing Details: Specifics on how each wall is constructed, including dimensions and materials.
  • Post Details: Information on the structural posts that support the building.
  • Header Details: Detailed drawings of the header construction above windows and doors.
  • Steel Truss Details: Layout and specifications for any steel trusses used in the structure.
  • Joining Details: Information on how various elements of the building are connected.
  • Electrical Drawing: A layout of the electrical plan, including the placement of outlets, switches, and fixtures.
  • Plumbing Drawing: Detailed plumbing layout, showing the placement of pipes, fixtures, and connections.
  • Material List: A comprehensive list of materials required for the construction of your home.
  • Slab Details: Information regarding the foundation slab, including dimensions and materials used.

Source Files Included:

  • CAD Files: Editable CAD files to modify and adapt the design to your specific needs.
  • SketchUp Files: 3D SketchUp models for a detailed and interactive view of the design.

Important Notes:

  • Digital Files Only: No physical printed plans are included with your purchase. All files are provided in a digital format for your convenience.
  • Consult a Professional: It is highly recommended to consult with a licensed builder or architect to ensure compliance with local building codes and regulations.
  • Personal Use Only: These plans are intended for personal use only. Redistribution, resale, or sharing of the files is strictly prohibited.
  • No Returns: Due to copyright laws and the nature of digital products, returns or exchanges are not available.

This plan is perfect for anyone looking to build their dream home with a touch of elegance and modern house aesthetic. Ready to bring your vision to life? Download your plan today and take the first step towards your serene homestead retreat.
