2 Story, 3-Bed Mountain House Plan with Vaulted Loft, and Basement Options, Hilltop Hideout Architectural Plans, Digital File (CAD, Pdf)
50' x 33' Mountain Farmhouse Plan with Vaulted Great Room, Loft, and Basement Options – Dream Home Plans
Explore this stunning 50' x 33' mountain farmhouse designed to blend rustic charm with modern elegance. Offering a spacious 1683 sq. ft. ground floor, 774 sq. ft. loft, and 1310 sq. ft. basement, this home features 3 bedrooms, 4 bathrooms, and a single-car garage. The vaulted great room, dining, and kitchen create a bright and open living space, complemented by large decks and a porch for outdoor relaxation.
This complete architectural plan set includes everything needed for construction: Floor Plans, Elevations, Foundation Plan, Roof Framing, Electrical and Plumbing Plans, and detailed sections.
Perfect for flat or sloped sites, this farmhouse design is ideal for families or short-term rentals. Plans are compliant with U.S. standards but may require local adaptations for seismic or hurricane codes.
>>Total Area: 1683 sq. ft. (ground) + 774 sq. ft. (loft) + 1310 sq. ft. (basement)
>>Bedrooms: 3
>>Bathrooms: 4
>>Garage: Single-car
>>Features: Vaulted ceilings, open floor plan, large decks
What is included:
-Project Overview
-General Notes
-Architectural Floor Plan
-Foundation Plan & Slab
-Wall Layout Plan
-Ceiling & Roof Plan & Framing
-Elevations
-Sections
-Door & Window Schedule
-Join Details (listed multiple times)
-Toilet Details
-Bathroom Details
-Electrical Plan
-Plumbing Plan
-Material Info
>>Digital Download Only-
-Printable on standard 24"x36" sheets. CAD files available.
-Note: Plans are copyrighted by Dream Home Plans for personal use only.
What's Included
What's Included in Your Plan
When you purchase this plan, you’ll receive a comprehensive set of digital drawings and details to guide you through every step of building your dream home. Each plan includes the following:
Important Notes
Digital Files Only: No physical printed plans are included with your purchase. All files are provided in a digital format for your convenience.
It is highly recommended to consult with a licensed builder or architect to ensure compliance with local building codes and regulations.
Personal Use Only: These plans are intended for personal use only. Redistribution, resale, or sharing of the files is strictly prohibited.
No Returns: Due to copyright laws and the nature of digital products, returns or exchanges are not available.
Source Files Included
CAD Files: Editable CAD files to modify and adapt the design to your specific needs.
SketchUp Files: 3D SketchUp models for a detailed and interactive view of the design.
This plan is perfect for anyone looking to build their dream home with a touch of elegance and modern house aesthetic. Ready to bring your vision to life? Download your plan today and take the first step towards your serene homestead retreat.
Drawings Included
Presentation Drawing: A visual overview of the design, showcasing the aesthetic and layout.
Working Drawing: Detailed drawings that include all necessary construction notes and specifications.
West & East Elevation: Side views of the house, showing the heights and finishes from the west and east perspectives.
South & North Elevation: Front and rear views of the house, outlining the heights and finishes from the south and north perspectives.
Section A-A': A cross-sectional view that details the interior structure along the A-A’ line.
Section B-B': A cross-sectional view that details the interior structure along the B-B’ line.
Section C-C': A cross-sectional view that details the interior structure along the C-C’ line.
Structural Layout: The foundational framework, including floor layouts and roof structures.
Wall Framing Details: Specifics on how each wall is constructed, including dimensions and materials.
Post Details: Information on the structural posts that support the building.
Header Details: Detailed drawings of the header construction above windows and doors.
Steel Truss Details: Layout and specifications for any steel trusses used in the structure.
Joining Details: Information on how various elements of the building are connected.
Electrical Drawing: A layout of the electrical plan, including the placement of outlets, switches, and fixtures.
Plumbing Drawing: Detailed plumbing layout, showing the placement of pipes, fixtures, and connections.
Material List: A comprehensive list of materials required for the construction of your home.
Slab Details: Information regarding the foundation slab, including dimensions and materials used.
