Plan 2503

No review yet. Write Review
Regular price
$299.00
Regular price
$999.00
Sale price
$299.00
Hurry! Only
0
units left in stock!
Trusted Image

The Tiny House Plan 2503 is a stylish and modern 21' x 21' cabin, perfect for those seeking a cozy yet functional living space. With its sleek design, large windows, and inviting outdoor area, this home blends contemporary aesthetics with practical simplicity, making it an excellent choice for a vacation retreat or compact living. Perfect for a Vacation Home, ADU, or Cozy Living

Specifications:

- Bedrooms: 2
- Bathrooms: 1
- Living Area: 441 SQFT
- Uncovered Deck: 147 SQFT
- Total Footprint: 588 SQFT
- Lot Coverage: 588 SQFT
- Unheated Area (Decks): 147 SQFT

Room Dimensions:
- Kitchen: 125 SQFT
- Living Room: 125 SQFT
- Loft: 75 SQFT
- Bathroom: 50 SQFT
- Bedroom: 53 SQFT
- Closet: 12 SQFT

Included Drawings:
A0.1 – Project Overview
A0.2 – General Notes
A1.1 – Architectural Floor Plan
A1.2 – Foundation Plan & Slab
A1.3 – Wall Layout Plan
A1.4 – Ceiling & Roof Plan & Framing
A2.1 – Elevation
A3.1 – Section
A4.1 – Door & Window Schedule
A4.2, A4.3, A4.4 – Join Details
A5.1 – Kitchen Details
A5.2 – Bathroom Details
E1.1 – Electrical Plan
P1.1 – Plumbing Plan
M1.1 – Material Info

Important Notes:
⚠️ Digital Download Only – No physical printed plans included.
⚠️ Code Compliance – Consult with a licensed builder or architect to ensure compliance with local regulations.
⚠️ For Personal Use Only – Redistribution or resale is prohibited.
⚠️ No Returns – Due to copyright laws, all sales are final.

This modern tiny house plan is designed for efficient living, making it ideal for a vacation retreat, rental property, or an affordable primary home. With simple construction details, it’s easy to build and customize to suit your needs.

What's Included in Your Plan

When you purchase this plan, you’ll receive a comprehensive set of digital drawings and details to guide you through every step of building your dream home. Each plan includes the following:

Drawings Included:

  • Presentation Drawing: A visual overview of the design, showcasing the aesthetic and layout.
  • Working Drawing: Detailed drawings that include all necessary construction notes and specifications.
  • West & East Elevation: Side views of the house, showing the heights and finishes from the west and east perspectives.
  • South & North Elevation: Front and rear views of the house, outlining the heights and finishes from the south and north perspectives.
  • Section A-A': A cross-sectional view that details the interior structure along the A-A’ line.
  • Section B-B': A cross-sectional view that details the interior structure along the B-B’ line.
  • Section C-C': A cross-sectional view that details the interior structure along the C-C’ line.
  • Structural Layout: The foundational framework, including floor layouts and roof structures.
  • Wall Framing Details: Specifics on how each wall is constructed, including dimensions and materials.
  • Post Details: Information on the structural posts that support the building.
  • Header Details: Detailed drawings of the header construction above windows and doors.
  • Steel Truss Details: Layout and specifications for any steel trusses used in the structure.
  • Joining Details: Information on how various elements of the building are connected.
  • Electrical Drawing: A layout of the electrical plan, including the placement of outlets, switches, and fixtures.
  • Plumbing Drawing: Detailed plumbing layout, showing the placement of pipes, fixtures, and connections.
  • Material List: A comprehensive list of materials required for the construction of your home.
  • Slab Details: Information regarding the foundation slab, including dimensions and materials used.

Source Files Included:

  • CAD Files: Editable CAD files to modify and adapt the design to your specific needs.
  • SketchUp Files: 3D SketchUp models for a detailed and interactive view of the design.

Important Notes:

  • Digital Files Only: No physical printed plans are included with your purchase. All files are provided in a digital format for your convenience.
  • Consult a Professional: It is highly recommended to consult with a licensed builder or architect to ensure compliance with local building codes and regulations.
  • Personal Use Only: These plans are intended for personal use only. Redistribution, resale, or sharing of the files is strictly prohibited.
  • No Returns: Due to copyright laws and the nature of digital products, returns or exchanges are not available.

This plan is perfect for anyone looking to build their dream home with a touch of elegance and modern house aesthetic. Ready to bring your vision to life? Download your plan today and take the first step towards your serene homestead retreat.
