Plan 2413 | Barndominium
- Regular price
- $495.00
- Regular price
-
$2,000.00 - Sale price
- $495.00
- Unit price
- per
Vendor : Dream Home Plans
Product Type :
Couldn't load pickup availability
Embark on your dream home journey with "Dream Home Plans," a 1575 sq ft barndominium modern farmhouse that seamlessly blends rustic charm with contemporary elegance. Designed to suit diverse landscapes, this digital architect plan is perfect for personal dwellings, vacation homes, or cabin retreats. Whether you're seeking custom plans for a 3-bedroom layout or building plans for a barndominium house, this download offers everything you need to get started. Featuring 2 bathroom plans and farmhouse floor plans, it's an ideal choice for those looking for detailed building blueprints and custom designs.
Details
-Main Level: 1575 q. ft.
-Covered Area: 423 sq. ft.
-Garage: 1575 sq. ft.
UNHEATED Sq Ft
-Garage: 1,519 sq. ft.
-Total Finished Area: 1575 Sq. Ft.
Width: 102 ' 4"
Depth: 43 ' 4"
Ridge Height (Calculated from main floor line): 17'
Roof Pitches" Primary 2/12, Secondary 4/12
Main Wall Height: 12'
Floors: 1
Bedrooms: 3
Bathrooms: 2
Garages: 3 cars
DRAWINGS INCLUDED
-01 GROUND FLOOR PLAN
-02 GROUND FLOOR PLAN(BASEMENT ENTRY)
-03 FIRST FLOOR PLAN
-04 BASEMENT PLAN
-SLAB PLAN LAYOUT SHOWING LOAD
BEARING WALL
-06 SECTIONS IN FLOOR PLAN
-07 SECTION A-A'
-08 SECTION B-B'
-09 EAST ELEVATION
-10 WEST ELEVATION
-11 NORTH ELEVATION
-12 SOUTH ELEVATION
-13 RAFTER DETAILS
-14 WALL DETAILS
-15 WALL AND WINDOW DETAILS
-16 EXTERIOR WALL FOUNDATION DETAILS
-17 Electrical Plan
-18 Plumbing details
-19 Material List
This modern barndominium blends luxury with comfort. Upon entering through the spacious three-car garage, you're welcomed by a stylish mudroom and a large, open living area ideal for family gatherings. The kitchen, with its walk-in pantry, seamlessly opens to the great room, ensuring no guest is overlooked. The Jonesboro plan offers a 3-bedroom setup: one with a shared bath and the other featuring a large vanity, soaking tub, and walk-in closet. Outdoors, the covered patio and stunning pergola create a perfect space for evening relaxation, especially when adorned with lights. Perfect for entertaining, this unique barndominium is designed for hosting memorable events. Explore these barndominium house plans, custom drafter-designed farmhouse plans, and floor plan renderings today.
Important Notes:
-No physical printed plans included; digital files only
-Consult with a licensed builder or architect for local code compliance
-Additional source files available for $99
-Plans are for personal use only; redistribution is prohibited
-Due to copyright laws, returns are not available
This plan is perfect for anyone looking to build their dream home with a touch of elegance and a modern farmhouse aesthetic. Ready to bring your vision to life? Download your plan today and take the first step towards your serene homestead retreat.
What's Included in Your Plan
When you purchase this plan, you’ll receive a comprehensive set of digital drawings and details to guide you through every step of building your dream home. Each plan includes the following:
Drawings Included:
- Presentation Drawing: A visual overview of the design, showcasing the aesthetic and layout.
- Working Drawing: Detailed drawings that include all necessary construction notes and specifications.
- West & East Elevation: Side views of the house, showing the heights and finishes from the west and east perspectives.
- South & North Elevation: Front and rear views of the house, outlining the heights and finishes from the south and north perspectives.
- Section A-A': A cross-sectional view that details the interior structure along the A-A’ line.
- Section B-B': A cross-sectional view that details the interior structure along the B-B’ line.
- Section C-C': A cross-sectional view that details the interior structure along the C-C’ line.
- Structural Layout: The foundational framework, including floor layouts and roof structures.
- Wall Framing Details: Specifics on how each wall is constructed, including dimensions and materials.
- Post Details: Information on the structural posts that support the building.
- Header Details: Detailed drawings of the header construction above windows and doors.
- Steel Truss Details: Layout and specifications for any steel trusses used in the structure.
- Joining Details: Information on how various elements of the building are connected.
- Electrical Drawing: A layout of the electrical plan, including the placement of outlets, switches, and fixtures.
- Plumbing Drawing: Detailed plumbing layout, showing the placement of pipes, fixtures, and connections.
- Material List: A comprehensive list of materials required for the construction of your home.
- Slab Details: Information regarding the foundation slab, including dimensions and materials used.
Source Files Included:
- CAD Files: Editable CAD files to modify and adapt the design to your specific needs.
- SketchUp Files: 3D SketchUp models for a detailed and interactive view of the design.
Important Notes:
- Digital Files Only: No physical printed plans are included with your purchase. All files are provided in a digital format for your convenience.
- Consult a Professional: It is highly recommended to consult with a licensed builder or architect to ensure compliance with local building codes and regulations.
- Personal Use Only: These plans are intended for personal use only. Redistribution, resale, or sharing of the files is strictly prohibited.
- No Returns: Due to copyright laws and the nature of digital products, returns or exchanges are not available.
This plan is perfect for anyone looking to build their dream home with a touch of elegance and modern house aesthetic. Ready to bring your vision to life? Download your plan today and take the first step towards your serene homestead retreat.
